The LBP223dw printer delivers an output speed up to 33ppm and is designed to produce consistent high quality output page after page.
Your compact black and white laser printer with professional capabilities, enjoy high quality black and white laser ptiner at speed.
A printer that works with you
The LBP223dw is compact and won’t take up much space, allowing you to sit alongside it to access it as you please.
Easily integrates into new environments
Your Canon LBP223dw is quick to set up, network ready and easy to integrate into your office print environment.
Take security to a whole new level
Eliminate unnecessary printing and maximise security surrounding sensitive documents with the LBP223dw’s innovative secure print features.
Maximise your productivity
Take your business to the next level with this fast black and white printer that’s loaded with tools to improve workflow and increase productivity.
A Salute to the environment
With automatic duplex printing, your LBP223dw significantly reduces paper waste. So now you can minimise your environmental impact and operating costs.
Wireless Connectivity
Your wireless Canon printer is network ready for multiple users. With one touch of the WPS button on the printer and router, you’re up and running.
| Printing Method | Monochrome Laser Beam Printing |
| Print Speed | |
| A4 | 33 ppm |
| Letter | 34 ppm |
| 2-sided | 28 ppm (A4) / 29 ppm (Letter) |
| Print Resolution | 600 x 600 dpi |
| Print Quality with Image Refinement Technology | 1,200 x 1,200 dpi (equivalent) |
| Warm-Up Time (From Power On) | 14 sec or less |
| First Print Out Time (FPOT) (approx.) | |
| A4 | 5.5 sec |
| Letter | 5.4 sec |
| Recovery Time (From Sleep Mode) | 4.0 sec or less |
| Print Language | UFR II, PCL 6 |
| Auto Duplex Print | Standard |
| Print Margins | Top/Bottom/Left/Right margin: 5 mm Top/Bottom/Left/Right margin: 10 mm (Envelope) |
| Paper Input (based on 80 g/m²) | |
| Standard Cassette | 250 sheets |
| Multi-Purpose Tray | 100 sheets |
| Optional Paper Feeder | 550 sheets |
| Maximum Paper Input Capacity | 900 sheets |
| Paper Output | 150 sheets |
| Paper Sizes | |
| Standard Cassette / Optional Paper Feeder | A4, B5, A5, A6, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian Legal Custom (min. 105.0 x 148.0 mm to max. 216.0 x 355.6 mm) |
| Multi-Purpose Tray | A4, B5, A5, A6, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian Legal, Index Card, Envelope (COM10, Monarch, C5, DL) Custom (min. 76.2 x 127.0 mm to max. 216.0 x 355.6 mm) |
| Available Paper Size for Auto Duplex Print | A4, Letter, Legal, Foolscap, Indian Legal |
| Paper Types | Plain, Thick, Coated, Recycled, Colour, Label, Postcard, Envelope |
| Paper Weight | |
| Standard Cassette / Optional Paper Feeder | 60 to 120 g/m2 |
| Multi-Purpose Tray | 60 to 163 g/m² |
| Standard Interfaces | |
| Wired | USB 2.0 High Speed, 10Base-T/100Base-TX/1000Base-T |
| Wireless | Wi-Fi 802.11b/g/n (Infrastructure mode, WPS, Direct Connection) |
| Network Protocol | |
| LPD, RAW, WSD-Print (IPv4, IPv6) | |
| TCP/IP Application Services | Bonjour (mDNS), HTTP, HTTPS, POP before SMTP (IPv4, IPv6), DHCP, ARP+PING, Auto IP, WINS (IPv4), DHCPv6 (IPv6) |
| Management | SNMPv1, SNMPv3 (IPv4, IPv6) |
| Network Security | |
| Wired | IP/Mac address filtering, HTTPS, SNMPv3, IEEE802.1x, IPSEC |
| Wireless | Infrastructure Mode: WEP (64/128 bit), WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES) Access Point Mode: WPA2-PSK (AES) |
| Other Features | Department ID |
| Mobile Solution | Canon PRINT Business, Canon Print Service, Apple® AirPrint®, Mopria® Print Service |
| Compatible Operating Systems | Windows®, Windows Server®, Mac® OS, Linux*1 |
| Software Included | Printer driver, Toner Status |
| Device Memory | 1 GB |
| Display | 5-Line LCD with vari-angle |
| Dimensions (W x D x H) (approx.) | 401 x 373 x 250 mm |
| Weight (approx.) | 8.8 kg |
| Power Consumption (approx.) | |
| Maximum (Operation) | 1,330 W or less |
| Average (Operation) | 480 W |
| Average (Standby) | 9.0 W |
| Average (Sleep) | 0.9 W (USB/ LAN / Wi-Fi) |
| Operating Environment | |
| Temperature | 10 – 30°C |
| Humidity | 20% – 80% RH (no condensation) |
| Power Requirements | AC 220 – 240 V (+/-10%), 50/60 Hz (+/-2 Hz) |
| Toner Cartridge*2 | |
| Standard | Cartridge 057: 3,100 pages (Bundled: 1,500 pages) |
| High | Cartridge 057H: 10,000 pages |
| Monthly Duty Cycle*3 | 80,000 pages |
| Paper Feeder | Cassette Feeding Unit-AH1 (550 sheets)
Paper Handling
Connectivity & Software
General
Optional Accessories
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Not sure which machine is right for you? Our sales team has an in-depth understanding of the capabilities of our machines and can guide you in selecting the copier or printer that suits your business needs. Book an obligation-free consultation with us and let us walk you through the options.
